JKL11: H-K9L平凸透镜
产品特点
-
材 料： 精退火K9光学玻璃
-
设计波长： 587.6nm
-
直径误差： +0.0/-0.1mm
-
中心厚度误差: ±0.2mm
-
面型不规则： 波长/4 @632.8nm
-
焦距误差（EFL）： ±2%
-
透镜定心误差： 3 分
-
表面光洁度： 3~4级
-
倒 边： 0.2mmX45°
- 镀 膜： 无
技术指标
|
JKL11: H-K9L平凸透镜 |
|||||||||
|
直径Dia.(mm) |
焦距EFL(mm) |
背焦BFL(mm) |
半径 R1(mm) |
中心厚度Tc(mm) |
边厚 Te(mm) |
未镀膜产品型号 |
AR@400-700nm产品型号 |
AR@650-1050nm产品型号 |
AR1000-1650nm产品型号 |
|
3 |
4.5 |
3.39 |
2.33 |
1.7 |
1.15 |
JKL11-003-004 |
JKL11-003-004-VIS |
JKL11-003-004-NIR |
JKL11-003-004-SWIR |
|
3 |
10 |
8.88 |
5.17 |
1.7 |
1.48 |
JKL11-003-010 |
JKL11-003-010-VIS |
JKL11-003-010-NIR |
JKL11-003-010-SWIR |
|
4 |
5 |
3.78 |
2.58 |
1.9 |
0.95 |
JKL11-004-005 |
JKL11-004-005-VIS |
JKL11-004-005-NIR |
JKL11-004-005-SWIR |
|
4 |
6.3 |
5.18 |
3.25 |
1.7 |
1.01 |
JKL11-004-006 |
JKL11-004-006-VIS |
JKL11-004-006-NIR |
JKL11-004-006-SWIR |
|
4 |
10 |
8.88 |
5.17 |
1.7 |
1.3 |
JKL11-004-010 |
JKL11-004-010-VIS |
JKL11-004-010-NIR |
JKL11-004-010-SWIR |
|
5 |
8 |
7.01 |
4.13 |
1.5 |
0.66 |
JKL11-005-008 |
JKL11-005-008-VIS |
JKL11-005-008-NIR |
JKL11-005-008-SWIR |
|
6 |
8 |
6.28 |
4.13 |
2.6 |
1.31 |
JKL11-006A-008 |
JKL11-006A-008-VIS |
JKL11-006A-008-NIR |
JKL11-006A-008-SWIR |
|
6 |
10 |
8.3 |
5.17 |
2.6 |
1.64 |
JKL11-006A-010 |
JKL11-006A-010-VIS |
JKL11-006A-010-NIR |
JKL11-006A-010-SWIR |
|
6 |
12.5 |
10.98 |
6.46 |
2.3 |
1.56 |
JKL11-006A-012 |
JKL11-006A-012-VIS |
JKL11-006A-012-NIR |
JKL11-006A-012-SWIR |
|
6 |
16 |
14.62 |
8.26 |
2.1 |
1.54 |
JKL11-006A-016 |
JKL11-006A-016-VIS |
JKL11-006A-016-NIR |
JKL11-006A-016-SWIR |
|
6 |
20 |
18.74 |
10.36 |
2 |
1.56 |
JKL11-006A-020 |
JKL11-006A-020-VIS |
JKL11-006A-020-NIR |
JKL11-006A-020-SWIR |
|
6 |
25 |
23.75 |
12.91 |
1.9 |
1.55 |
JKL11-006A-025 |
JKL11-006A-025-VIS |
JKL11-006A-025-NIR |
JKL11-006A-025-SWIR |
|
6 |
40 |
38.87 |
20.65 |
1.7 |
1.48 |
JKL11-006A-040 |
JKL11-006A-040-VIS |
JKL11-006A-040-NIR |
JKL11-006A-040-SWIR |
|
6 |
63 |
61.82 |
32.5 |
1.7 |
1.56 |
JKL11-006A-063 |
JKL11-006A-063-VIS |
JKL11-006A-063-NIR |
JKL11-006A-063-SWIR |
|
6.3 |
8 |
6.28 |
4.13 |
2.6 |
1.14 |
JKL11-006-008 |
JKL11-006-008-VIS |
JKL11-006-008-NIR |
JKL11-006-008-SWIR |
|
6.3 |
10 |
8.3 |
5.17 |
2.6 |
1.53 |
JKL11-006-010 |
JKL11-006-010-VIS |
JKL11-006-010-NIR |
JKL11-006-010-SWIR |
|
6.3 |
12.5 |
10.98 |
6.46 |
2.3 |
1.48 |
JKL11-006-012 |
JKL11-006-012-VIS |
JKL11-006-012-NIR |
JKL11-006-012-SWIR |
|
6.3 |
16 |
14.62 |
8.26 |
2.1 |
1.48 |
JKL11-006-016 |
JKL11-006-016-VIS |
JKL11-006-016-NIR |
JKL11-006-016-SWIR |
|
6.3 |
20 |
18.74 |
10.36 |
2 |
1.51 |
JKL11-006-020 |
JKL11-006-020-VIS |
JKL11-006-020-NIR |
JKL11-006-020-SWIR |
|
6.3 |
25 |
23.75 |
12.91 |
1.9 |
1.51 |
JKL11-006-025 |
JKL11-006-025-VIS |
JKL11-006-025-NIR |
JKL11-006-025-SWIR |
|
6.3 |
40 |
38.87 |
20.65 |
|
1.46 |
JKL11-006-040 |
JKL11-006-040-VIS |
JKL11-006-040-NIR |
JKL11-006-040-SWIR |
|
6.3 |
63 |
61.82 |
32.5 |
1.7 |
1.55 |
JKL11-006-063 |
JKL11-006-063-VIS |
JKL11-006-063-NIR |
JKL11-006-063-SWIR |
|
10 |
12.5 |
9.93 |
6.46 |
3.9 |
1.53 |
JKL11-010-012 |
JKL11-010-012-VIS |
JKL11-010-012-NIR |
JKL11-010-012-SWIR |
|
10 |
16 |
13.89 |
8.26 |
3.2 |
1.52 |
JKL11-010-016 |
JKL11-010-016-VIS |
JKL11-010-016-NIR |
JKL11-010-016-SWIR |
|
10 |
20 |
18.22 |
10.36 |
2.8 |
1.51 |
JKL11-010-020 |
JKL11-010-020-VIS |
JKL11-010-020-NIR |
JKL11-010-020-SWIR |
|
10 |
25 |
23.35 |
12.91 |
2.5 |
1.49 |
JKL11-010-025 |
JKL11-010-025-VIS |
JKL11-010-025-NIR |
JKL11-010-025-SWIR |
|
10 |
31.5 |
29.99 |
16.27 |
2.3 |
1.51 |
JKL11-010-032 |
JKL11-010-032-VIS |
JKL11-010-032-NIR |
JKL11-010-032-SWIR |
|
10 |
40 |
38.61 |
20.65 |
2.1 |
1.49 |
JKL11-010-040 |
JKL11-010-040-VIS |
JKL11-010-040-NIR |
JKL11-010-040-SWIR |
|
10 |
50 |
48.72 |
25.84 |
2 |
1.51 |
JKL11-010-050 |
JKL11-010-050-VIS |
JKL11-010-050-NIR |
JKL11-010-050-SWIR |
|
10 |
63 |
61.69 |
32.5 |
1.9 |
1.51 |
JKL11-010-063 |
JKL11-010-063-VIS |
JKL11-010-063-NIR |
JKL11-010-063-SWIR |
|
10 |
100 |
98.89 |
51.64 |
1.7 |
1.46 |
JKL11-010-100 |
JKL11-010-100-VIS |
JKL11-010-100-NIR |
JKL11-010-100-SWIR |
|
12 |
20.3 |
18.34 |
10.5 |
3 |
1.12 |
JKL11-012-020 |
JKL11-012-020-VIS |
JKL11-012-020-NIR |
JKL11-012-020-SWIR |
|
12 |
25 |
23 |
12.91 |
3 |
1.52 |
JKL11-012-025 |
JKL11-012-025-VIS |
JKL11-012-025-NIR |
JKL11-012-025-SWIR |
|
15 |
60 |
58.51 |
31.02 |
2.3 |
1.38 |
JKL11-015-060 |
JKL11-015-060-VIS |
JKL11-015-060-NIR |
JKL11-015-060-SWIR |
|
16 |
20 |
16.9 |
10.36 |
4.8 |
1.02 |
JKL11-016-020 |
JKL11-016-020-VIS |
JKL11-016-020-NIR |
JKL11-016-020-SWIR |
|
16 |
25 |
22.36 |
12.91 |
4 |
1.22 |
JKL11-016-025 |
JKL11-016-025-VIS |
JKL11-016-025-NIR |
JKL11-016-025-SWIR |
|
16 |
31.5 |
29.13 |
16.27 |
3.6 |
1.5 |
JKL11-016-032 |
JKL11-016-032-VIS |
JKL11-016-032-NIR |
JKL11-016-032-SWIR |
|
16 |
40 |
37.95 |
20.65 |
3.1 |
1.49 |
JKL11-016-040 |
JKL11-016-040-VIS |
JKL11-016-040-NIR |
JKL11-016-040-SWIR |
|
16 |
50 |
48.2 |
25.84 |
2.8 |
1.53 |
JKL11-016-050 |
JKL11-016-050-VIS |
JKL11-016-050-NIR |
JKL11-016-050-SWIR |
|
16 |
63 |
61.29 |
32.5 |
2.5 |
1.5 |
JKL11-016-063 |
JKL11-016-063-VIS |
JKL11-016-063-NIR |
JKL11-016-063-SWIR |
|
16 |
80 |
78.47 |
41.3 |
2.3 |
1.52 |
JKL11-016-080 |
JKL11-016-080-VIS |
JKL11-016-080-NIR |
JKL11-016-080-SWIR |
|
16 |
100 |
98.62 |
51.64 |
2.1 |
1.48 |
JKL11-016-100 |
JKL11-016-100-VIS |
JKL11-016-100-NIR |
JKL11-016-100-SWIR |
|
16 |
160 |
158.75 |
82.62 |
1.9 |
1.51 |
JKL11-016-160 |
JKL11-016-160-VIS |
JKL11-016-160-NIR |
JKL11-016-160-SWIR |
|
20 |
30 |
27.03 |
15.5 |
4.5 |
0.84 |
JKL11-020-030 |
JKL11-020-030-VIS |
JKL11-020-030-NIR |
JKL11-020-030-SWIR |
|
20 |
50 |
47.23 |
25.84 |
4.2 |
2.19 |
JKL11-020-050 |
JKL11-020-050-VIS |
JKL11-020-050-NIR |
JKL11-020-050-SWIR |
|
25 |
25.4 |
18.03 |
13.11 |
11.16 |
2 |
JKL11-025-025 |
JKL11-025-025-VIS |
JKL11-025-025-NIR |
JKL11-025-025-SWIR |
|
25 |
26.7 |
20.44 |
13.8 |
9.5 |
1.55 |
JKL11-025-027 |
JKL11-025-027-VIS |
JKL11-025-027-NIR |
JKL11-025-027-SWIR |
|
25 |
31.5 |
26.33 |
16.27 |
7.86 |
2 |
JKL11-025-032 |
JKL11-025-032-VIS |
JKL11-025-032-NIR |
JKL11-025-032-SWIR |
|
25 |
40 |
35.89 |
20.65 |
6.21 |
2 |
JKL11-025-040 |
JKL11-025-040-VIS |
JKL11-025-040-NIR |
JKL11-025-040-SWIR |
|
25 |
50 |
46.1 |
25.84 |
4.7 |
1.47 |
JKL11-025-050 |
JKL11-025-050-VIS |
JKL11-025-050-NIR |
JKL11-025-050-SWIR |
|
25 |
63 |
59.47 |
32.5 |
4 |
1.5 |
JKL11-025-063 |
JKL11-025-063-VIS |
JKL11-025-063-NIR |
JKL11-025-063-SWIR |
|
25 |
76 |
73.63 |
39.28 |
3.6 |
1.56 |
JKL11-025-076 |
JKL11-025-076-VIS |
JKL11-025-076-NIR |
JKL11-025-076-SWIR |
|
25 |
80 |
77.39 |
41.3 |
3.94 |
2 |
JKL11-025-080 |
JKL11-025-080-VIS |
JKL11-025-080-NIR |
JKL11-025-080-SWIR |
|
25 |
100 |
97.67 |
51.64 |
3.54 |
2 |
JKL11-025-100 |
JKL11-025-100-VIS |
JKL11-025-100-NIR |
JKL11-025-100-SWIR |
|
25 |
125 |
122.88 |
64.55 |
3.22 |
2 |
JKL11-025-125 |
JKL11-025-125-VIS |
JKL11-025-125-NIR |
JKL11-025-125-SWIR |
|
25 |
160 |
158.06 |
82.62 |
2.95 |
2 |
JKL11-025-160 |
JKL11-025-160-VIS |
JKL11-025-160-NIR |
JKL11-025-160-SWIR |
|
25 |
200 |
198.19 |
103.28 |
2.76 |
2 |
JKL11-025-200 |
JKL11-025-200-VIS |
JKL11-025-200-NIR |
JKL11-025-200-SWIR |
|
25 |
250 |
248.57 |
129.24 |
2.61 |
2 |
JKL11-025-250 |
JKL11-025-250-VIS |
JKL11-025-250-NIR |
JKL11-025-250-SWIR |
|
25 |
315 |
313.68 |
162.79 |
2 |
1.5 |
JKL11-025-315 |
JKL11-025-315-VIS |
JKL11-025-315-NIR |
JKL11-025-315-SWIR |
|
25 |
400 |
397.56 |
206.1 |
2.38 |
2 |
JKL11-025-400 |
JKL11-025-400-VIS |
JKL11-025-400-NIR |
JKL11-025-400-SWIR |
|
25 |
500 |
498.47 |
258.18 |
2.3 |
2 |
JKL11-025-500 |
JKL11-025-500-VIS |
JKL11-025-500-NIR |
JKL11-025-500-SWIR |
|
25 |
630 |
628.82 |
325.58 |
1.78 |
1.54 |
JKL11-025-630 |
JKL11-025-630-VIS |
JKL11-025-630-NIR |
JKL11-025-630-SWIR |
|
25 |
800 |
798.88 |
413.44 |
1.7 |
1.5 |
JKL11-025-800 |
JKL11-025-800-VIS |
JKL11-025-800-NIR |
JKL11-025-800-SWIR |
|
25 |
1000 |
998.83 |
516.5 |
2.15 |
2 |
JKL11-025-1000 |
JKL11-025-1000-VIS |
JKL11-025-1000-NIR |
JKL11-025-1000-SWIR |
|
25 |
1600 |
1593.27 |
826.88 |
2.09 |
2 |
JKL11-025-1600 |
JKL11-025-1600-VIS |
JKL11-025-1600-NIR |
JKL11-025-1600-SWIR |
|
25 |
2000 |
1992 |
1033.6 |
2.08 |
2 |
JKL11-025-2000 |
JKL11-025-2000-VIS |
JKL11-025-2000-NIR |
JKL11-025-2000-SWIR |
|
25 |
2500 |
2490.34 |
1292 |
2.06 |
2 |
JKL11-025-2500 |
JKL11-025-2500-VIS |
JKL11-025-2500-NIR |
JKL11-025-2500-SWIR |
|
30 |
40 |
34.1 |
20.67 |
8.95 |
2.5 |
JKL11-030-040 |
JKL11-030-040-VIS |
JKL11-030-040-NIR |
JKL11-030-040-SWIR |
|
30 |
50 |
45.19 |
25.84 |
7.3 |
2.5 |
JKL11-030-050 |
JKL11-030-050-VIS |
JKL11-030-050-NIR |
JKL11-030-050-SWIR |
|
30 |
63 |
58.82 |
32.5 |
6.17 |
2.5 |
JKL11-030-063 |
JKL11-030-063-VIS |
JKL11-030-063-NIR |
JKL11-030-063-SWIR |
|
30 |
80 |
76.41 |
41.3 |
5.32 |
2.5 |
JKL11-030-080 |
JKL11-030-080-VIS |
JKL11-030-080-NIR |
JKL11-030-080-SWIR |
|
30 |
100 |
96.81 |
51.64 |
4.73 |
2.5 |
JKL11-030-100 |
JKL11-030-100-VIS |
JKL11-030-100-NIR |
JKL11-030-100-SWIR |
|
30 |
125 |
122.1 |
64.55 |
4.27 |
2.5 |
JKL11-030-125 |
JKL11-030-125-VIS |
JKL11-030-125-NIR |
JKL11-030-125-SWIR |
|
30 |
160 |
157.32 |
82.62 |
3.87 |
2.5 |
JKL11-030-160 |
JKL11-030-160-VIS |
JKL11-030-160-NIR |
JKL11-030-160-SWIR |
|
30 |
200 |
197.48 |
103.28 |
3.6 |
2.5 |
JKL11-030-200 |
JKL11-030-200-VIS |
JKL11-030-200-NIR |
JKL11-030-200-SWIR |
|
30 |
250 |
247.86 |
129.24 |
3.37 |
2.5 |
JKL11-030-250 |
JKL11-030-250-VIS |
JKL11-030-250-NIR |
JKL11-030-250-SWIR |
|
30 |
500 |
497.67 |
258.18 |
2.94 |
2.5 |
JKL11-030-500 |
JKL11-030-500-VIS |
JKL11-030-500-NIR |
JKL11-030-500-SWIR |
|
40 |
40 |
28.04 |
20.67 |
17.95 |
2.5 |
JKL11-040-040* |
JKL11-040-040-VIS* |
JKL11-040-040-NIR* |
JKL11-040-040-SWIR* |
|
40 |
50 |
42.14 |
25.84 |
11.98 |
2.5 |
JKL11-040-050 |
JKL11-040-050-VIS |
JKL11-040-050-NIR |
JKL11-040-050-SWIR |
|
40 |
63 |
56.75 |
32.5 |
9.38 |
2.5 |
JKL11-040-063 |
JKL11-040-063-VIS |
JKL11-040-063-NIR |
JKL11-040-063-SWIR |
|
40 |
80 |
74.93 |
41.3 |
7.67 |
2.5 |
JKL11-040-080 |
JKL11-040-080-VIS |
JKL11-040-080-NIR |
JKL11-040-080-SWIR |
|
40 |
100 |
95.7 |
51.64 |
6.53 |
2.5 |
JKL11-040-100 |
JKL11-040-100-VIS |
JKL11-040-100-NIR |
JKL11-040-100-SWIR |
|
40 |
125 |
121.26 |
64.55 |
5.68 |
2.5 |
JKL11-040-125 |
JKL11-040-125-VIS |
JKL11-040-125-NIR |
JKL11-040-125-SWIR |
|
40 |
160 |
156.73 |
82.62 |
4.96 |
2.5 |
JKL11-040-160 |
JKL11-040-160-VIS |
JKL11-040-160-NIR |
JKL11-040-160-SWIR |
|
40 |
200 |
197.07 |
103.28 |
4.45 |
2.5 |
JKL11-040-200 |
JKL11-040-200-VIS |
JKL11-040-200-NIR |
JKL11-040-200-SWIR |
|
40 |
250 |
247.61 |
129.24 |
4.06 |
2.5 |
JKL11-040-250 |
JKL11-040-250-VIS |
JKL11-040-250-NIR |
JKL11-040-250-SWIR |
|
40 |
500 |
497.83 |
258.18 |
3.28 |
2.5 |
JKL11-040-500 |
JKL11-040-500-VIS |
JKL11-040-500-NIR |
JKL11-040-500-SWIR |
|
45 |
100 |
96.4 |
51.9 |
6.1 |
0.97 |
JKL11-045-100 |
JKL11-045-100-VIS |
JKL11-045-100-NIR |
JKL11-045-100-SWIR |
|
45 |
120 |
116 |
62.2 |
6.1 |
1.89 |
JKL11-045-120 |
JKL11-045-120-VIS |
JKL11-045-120-NIR |
JKL11-045-120-SWIR |
|
50 |
63 |
53.22 |
32.5 |
14.73 |
3 |
JKL11-050-063 |
JKL11-050-063-VIS |
JKL11-050-063-NIR |
JKL11-050-063-SWIR |
|
50 |
80 |
72.45 |
41.3 |
11.43 |
3 |
JKL11-050-080 |
JKL11-050-080-VIS |
JKL11-050-080-NIR |
JKL11-050-080-SWIR |
|
50 |
100 |
93.77 |
51.64 |
9.45 |
3 |
JKL11-050-100 |
JKL11-050-100-VIS |
JKL11-050-100-NIR |
JKL11-050-100-SWIR |
|
50 |
160 |
155.47 |
82.62 |
6.87 |
3 |
JKL11-050-160 |
JKL11-050-160-VIS |
JKL11-050-160-NIR |
JKL11-050-160-SWIR |
|
50 |
250 |
246.7 |
129.24 |
5.44 |
3 |
JKL11-050-250 |
JKL11-050-250-VIS |
JKL11-050-250-NIR |
JKL11-050-250-SWIR |
|
50 |
500 |
497.21 |
258.18 |
4.21 |
3 |
JKL11-050-500 |
JKL11-050-500-VIS |
JKL11-050-500-NIR |
JKL11-050-500-SWIR |
|
63 |
100 |
90.96 |
51.64 |
13.72 |
3 |
JKL11-063-100 |
JKL11-063-100-VIS |
JKL11-063-100-NIR |
JKL11-063-100-SWIR |
|
63 |
125 |
117.62 |
64.55 |
11.21 |
3 |
JKL11-063-125 |
JKL11-063-125-VIS |
JKL11-063-125-NIR |
JKL11-063-125-SWIR |
|
63 |
160 |
153.91 |
82.62 |
9.24 |
3 |
JKL11-063-160 |
JKL11-063-160-VIS |
JKL11-063-160-NIR |
JKL11-063-160-SWIR |
|
63 |
250 |
245.74 |
129.24 |
6.9 |
3 |
JKL11-063-250 |
JKL11-063-250-VIS |
JKL11-063-250-NIR |
JKL11-063-250-SWIR |
|
63 |
500 |
496.74 |
258.18 |
4.93 |
3 |
JKL11-063-500 |
JKL11-063-500-VIS |
JKL11-063-500-NIR |
JKL11-063-500-SWIR |
|
63 |
1000 |
997.64 |
516.5 |
3.96 |
3 |
JKL11-063-1000 |
JKL11-063-1000-VIS |
JKL11-063-1000-NIR |
JKL11-063-1000-SWIR |
|
80 |
150 |
140.69 |
77.52 |
14.12 |
3 |
JKL11-080-150 |
JKL11-080-150-VIS |
JKL11-080-150-NIR |
JKL11-080-150-SWIR |
|
80 |
300 |
294.56 |
155.04 |
8.25 |
3 |
JKL11-080-300 |
JKL11-080-300-VIS |
JKL11-080-300-NIR |
JKL11-080-300-SWIR |
|
80 |
500 |
495.54 |
258.18 |
6.12 |
3 |
JKL11-080-500 |
JKL11-080-500-VIS |
JKL11-080-500-NIR |
JKL11-080-500-SWIR |
|
80 |
1000 |
996.02 |
516.82 |
4.6 |
3.05 |
JKL11-080-1000 |
JKL11-080-1000-VIS |
JKL11-080-1000-NIR |
JKL11-080-1000-SWIR |
|
80 |
2000 |
1997.52 |
1033.65 |
3.76 |
2.99 |
JKL11-080-2000 |
JKL11-080-2000-VIS |
JKL11-080-2000-NIR |
JKL11-080-2000-SWIR |
|
100 |
160 |
146.25 |
82.62 |
20.85 |
4 |
JKL11-100-160 |
JKL11-100-160-VIS |
JKL11-100-160-NIR |
JKL11-100-160-SWIR |
|
100 |
250 |
241.37 |
129.24 |
14.05 |
4 |
JKL11-100-250 |
JKL11-100-250-VIS |
JKL11-100-250-NIR |
JKL11-100-250-SWIR |
|
100 |
500 |
494.13 |
258.18 |
8.89 |
4 |
JKL11-100-500 |
JKL11-100-500-VIS |
JKL11-100-500-NIR |
JKL11-100-500-SWIR |
